Khoom Description

Choj preloading ton hnab yog ib hom kev hloov pauv ntim ntim siv hauv choj engineering rau preloading. Lawv feem ntau yog siv los simulate cov loads uas yuav tau ntsib thaum lub sij hawm tsim choj, thiaj li yuav soj ntsuam lub zog, stability, thiab kev sib haum xeeb ntawm tus choj txhawb los yog lub hauv paus.

Khoom siv thiab cov qauv
Khoom siv: Feem ntau yog ua los ntawm siab -lub zog polypropylene (PP) woven npuag. Sab nrauv PP puag ntaub yog kho nrog UV tsis kam, uas tuaj yeem tiv thaiv cov khoom los ntawm kev tawg vim raug tshav ntuj. Qee lub hnab tuj muaj cov ntaub ntawv sib xyaw polyethylene (PE) zaj duab xis ntawm txheej txheej sab hauv, tsim cov txheej txheem dej tsis zoo uas tiv thaiv dej nkag.

Structure: Hauv qab siv tus ntoo khaub lig- hauv qab lossis kab sib chaws- hauv qab qauv kom cuam tshuam qhov hnyav ntawm cov xuab zeb thiab pob zeb thiab tiv thaiv hauv qab tearing. Cov kab rov tav ntxiv cov hlua khi ntxiv yog ntxiv rau ob sab los txhim kho kev ruaj ntseg tag nrho. Plaub lub ces kaum yog nruab nrog lifting straps, thiab kev sib txuas ntawm lub lifting straps thiab lub hnab lub cev yog sewn nrog ob threads los yog bonded los ntawm tshav kub melting kom muaj kev ruaj ntseg load- bearing.

Yam ntxwv

Tus nqi siab -kev ua tau zoo: Nws tuaj yeem siv ncaj qha rau cov xuab zeb, pob zeb thiab lwm yam khoom siv muaj nyob rau ntawm qhov chaw tsim kho rau kev sau, tsis tas yuav muaj kev yuav khoom tshwj xeeb ntxiv, uas tuaj yeem txuag tau 30%-50% ntawm cov nqi ntim khoom. Cov hnab ntim khoob tuaj yeem ntim tau, uas tuaj yeem txuag qhov chaw cia, thiab tuaj yeem rov qab siv tau 5-10 zaug, nrog tus nqi qis ib zaug.

Kev ua haujlwm yooj yim: Qhov chaw noj zaub mov sab saum toj muaj txoj kab uas hla tshaj 50cm, uas yog tsim rau cov tshuab filling lossis phau ntawv ceev filling. Qhov chaw nres nkoj tawm hauv qab yog nruab nrog ib txoj hlua los yog lub valve, uas tuaj yeem ua tiav cov khoom xa tawm. Lub sijhawm - lub hnab ntim ib zaug yog luv luv rau hauv 5 feeb. Cov plaub - cov hlua khi yog dav rau 8cm, uas tuaj yeem tiv taus qhov hnyav ntawm 2 tons, yog sib xws nrog ntau yam khoom nqa nqa, thiab cov square tsim yog yooj yim rau stacking, uas tuaj yeem txhim kho qhov kev siv ntawm qhov chaw cia.

Muaj kev nyab xeeb thiab txhim khu kev qha: Los ntawm kev ntsuas kev poob qis, kev ntsuas kev sib tsoo saum toj kawg nkaus thiab lwm yam kev kuaj xyuas engineering, lub peev xwm nqa tau tshaj 2 tons, ua tau raws li qhov yuav tsum tau ua ntawm "Technical Specifications for Construction of Highway Bridges and Culverts". Kev tsim qauv sealing tuaj yeem ua kom tsis muaj paug thaum lub sijhawm thauj mus los thiab tsis txhob muaj kuab paug ntawm tus choj qauv.

Specification qhov ntev

Qhov loj tuaj yeem hloov kho raws li cov kev xav tau tshwj xeeb xws li choj hla thiab kev txhawb nqa qhov siab. Qhov ntau thiab tsawg muaj xws li 90cm × 90cm × 110cm, 100cm × 100cm × 120cm, thiab lwm yam. Lub peev xwm yog feem ntau ntawm 500 thiab 2000L, thiab nws tuaj yeem txhawb nqa qhov hnyav ntawm 0.5 mus rau 3 tons.

Daim ntawv thov scenario

Nws yog tsuas yog siv nyob rau hauv cov xwm txheej xws li preloading ntawm formwork kev txhawb nqa rau cam khwb cia- nyob rau hauv - qhov chaw lub thawv girders, loading ntawm steel truss qauv ntawm ncua kev kawm ntawv choj, preloading ntawm dai pob tawb thiab nyob rau hauv cable baskets thaum lub sij hawm cantilever casting, thiab preloading ntawm sab spans thiab mus rau lub choj. Los ntawm kev simulating qhov hnyav ntawm cov pob zeb lossis lwm yam khoom thauj, nws yog siv los ntsuas kev nyab xeeb ntawm tus choj qauv.

Cov khoom tsim tawm

vim li cas xaiv peb

Vim li cas thiaj xaiv peb ua koj tus khub rau Square Jumbo Hnab?

Vertical Integration: Kev tswj tag nrho los ntawm cov khoom siv raw mus rau cov khoom tiav

Peb ua haujlwm tag nrho kev lag luam saw, npog polypropylene yarn extrusion, weaving, thiab tiav - hnab xaws.
Qhov no ua kom zoo ib yam, raws li peb tswj txhua cov xov paj los ntawm qhov chaw, tshem tawm cov kev pheej hmoo cuam tshuam nrog cov ntaub yuav khoom.

Cov ntaub ntawv -Triven Quality Assurance: Tsis Muaj Cov Lus Cog Tseg

Peb muab qhov tseem ceeb ntawm cov ntaub ntawv tso cai tshaj li kev lees paub.
Txhua pawg ntawm cov ntaub npuag tau dhau los ua ntej- kev tshuaj xyuas ntau lawm, suav nrog kev ntsuas qhov hnyav thiab tensile lub zog, txhawm rau ua raws li cov qauv.

Scalable Supply nrog Flexible Customization

Peb cov kab ntau lawm automated ua kom muaj peev xwm txhua hli txog li 1 lab lub hnab, ua tau raws li koj qhov ntev -lub sij hawm, loj- teev qhov xav tau yam tsis muaj stockouts.

Ib qho kev sib koom ua qauv tsom rau kev txhawb nqa cov lag luam wholesale

Nws muab rau koj thiab koj pab neeg nrog kev paub txog cov khoom, kev xaiv cov ntawv thov, thiab kev txhawb nqa kev tshaj lij. Nws kuj teb tam sim ntawd rau txhua yam teeb meem uas koj ntsib nyob rau pem hauv ntej kawg.
